IOP and IOA Module Specifications
4-port Ethernet IOP Module
Beta Draft Confidential
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/03A-37
Physical Interfaces
Four RJ45-8 (modular jack) connectors (two-pair, category 5 UTP) or four Media
Independent Interface (MII) connectors
Interface Standards
802.3-compliant 100Base-TX (10 or 100 Mbps operation), full- or half-duplex, and
internal and external loopback, full- or half-duplex.
Management Standards
• RFC 1398 Ethernet MIB
• RFC 1213 TCP/IP-based Internet MIB
NEBS
• GR-63-CORE
• GR-1089-CORE
Agency Approvals
EN55022 Class A (CISPR), EN50082, FCC Part 15 Class A
Module Status Indicators
LEDs: Good (green), Failed (red)
LED State Status
Good ON Normal operation
Failed ON Module failure
Redundant ON Module online; redundant module installed and offline
Redundant OFF Module online; no redundant module installed
Redundant BLINKING Module offline; redundant module installed and online
