IOP and IOA Module Specifications
32-port Channelized T1/E1 FR/IP IOM
Beta Draft Confidential
A-64/5/03 CBX 500 Multiservice WAN Switch Hardware Installation Guide
32-port Channelized T1/E1 FR/IP IOM
The 32-Port Channelized T1/E1 Frame Relay/Internet Protocol (FR/IP) input/output
module (IOM) for the CBX 500 switch provides 32 T1/E1 channelized physical ports
on the input/output adapter (IOA). The CBX 500 switch supports a maximum of ten
32-Port Channelized T1/E1 FR/IP IOMs per chassis.
Specifications
Physical Dimensions
Height: 16 in. (40.6 cm)
Width: 1 in. (2.5 cm)
Depth: 11 in. (27.9 cm)
Weight: 4.5 lbs. (3.5 lbs. for the IOP and 1.0 lb. for the IOA)
Power Requirements: 90 watts
Temperature Range
0° to 50°C(32° to 122°F)
Agency Approvals
• ITU and European Telecommunications Standards Institute (ETSI) standards
• Electromagnetic Emissions Certifications
– Federal Communications Commission (FCC) Part 15 Class A
– EN55022 (CISPR Class A)
– Network Equipment-Building Standards (NEBS) GR-63-CORE,
GR-1089-CORE
– Underwriters Laboratories (UL) 1950, EN 60950
