Specifications and Safety Warnings
Power Cord Requirements
Beta Draft Confidential
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/032-9
Power Cord Requirements
The CBX 500 power cord is connected via a three-prong plug that grounds the switch
and polarizes the connection. The ground connector must be grounded properly.
Table 2-4 lists the country requirements for the plug types and their ratings.
Note – The AC power cord must be terminated with an IEC 320 receptacle.
Table 2-4. AC Power Cord Requirements
Country AC Power Cord Type and Rating
USA and Canada NEMA 5-15 15A/125 VAC
U.K. BS 1363 10A/240 VAC
Australia AS 3112 10A/240 VAC
Japan JIS 8303 15A/125 VAC
Switzerland SEV 1011 10A/220-240 VAC
Germany CEE7 VII 16A/250 VAC
