Beta Draft Confidential
Redundancy
Redundancy Manager
D-84/5/03 CBX 500 Multiservice WAN Switch Hardware Installation Guide
NMS Support
Users are required to specify which modules in the switch are redundant and in which
slots the modules reside. For redundant SPs, the NMS shows the back panel with a
graphical representation of a redundant SP adapter module occupying the middle two
slots in the switch. To initially bring up the switch, the NMS requires you to have an
SP configured in Slot 1; however, the SP can physically reside in Slot 1 or Slot 2.
The NMS also enables a user to manually switch operation from an active SP module
to the redundant SP module. The reset procedure is the same as if the redundant
module detected a failure with the active module.
