Beta Draft Confidential
Installing and Removing Modules
Switch Processor Module
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/036-3
Switch Processor Module
Removing an SP Module
Figure 6-1. Removing a Switch Processor (SP) Module
!
Caution –
• You cannot hot-swap the main SP or SPA module on an operational switch unless a
redundant SP module is installed and active at the time. You cannot hot-swap to replace the
active SP module or the associated PCMCIA card.
• If the switch has a redundant SP configuration, you must first change the status of the
component to be replaced from active to redundant before removing/replacing it. See the
B-STDX, CBX, and GX Switch Module Configuration Guide for information about
switching to a redundant card, using NavisCore.
