Determining the Operating Status
Status LEDs
Beta Draft Confidential
5-24/5/03 CBX 500 Multiservice WAN Switch Hardware Installation Guide
Status LEDs
The status LEDs on the CBX 500’s modules indicate the operating status of the switch
and of each module. You can monitor these LEDs locally on the switch, or remotely
through the NMS.
Switch Status LEDs
The overall status of the switch is indicated by the Good, Marginal, and Failed status
LEDs at the top of the SP module. These LEDs indicate the status of the switch, but
not of the SP module itself.
Table 5-1. Switch Status LEDs on SP Module
LED Condition Indicates
Good (Green) ON The switch is fully operational; no errors have been detected.
Marginal (Yellow) ON The switch hardware is operational but the software
configuration has not been downloaded; or a non-fatal error
condition exists on the switch.
Failed (Red) ON The switch detected an operational error condition.
