IOP and IOA Module Specifications
8-port Subrate Module
Beta Draft Confidential
A-404/5/03 CBX 500 Multiservice WAN Switch Hardware Installation Guide
8-port Subrate Module
The 8-port Subrate DS3 FR/IP Input/Output module (IOM) enables the CBX 500 to
operate at various speeds that are less than the DS3 line rate of 45 Mbps, and to
operate as a multiservice switch by providing Internet Protocol (IP) routing for
cell-based IP traffic, Frame Relay (FR) switching, and Frame Relay-to-ATM
interworking.
Specifications
Physical Dimensions
Height: 17.2 in. (43.64 cm)
Width: .92 in. (2.3 cm)
Depth: 11 in. (27.9 cm)
Weight: 5 lb (2.3 kg)
Power Requirements
105 Watts
Temperature Range
0° to 50°C(32° to 122°F)
Agency Approvals Electromagnetic Emissions Certifications
• FCC Part 15 Class A
• EN55022 (CISPR Class A)
• NEBS GR-63-CORE, GR-1089-CORE
• UL 1950, EN 60950
• International Telecommunications Union (ITU) standards
