IOP and IOA Module Specifications
8-port DS3 and E3 ATM UNI IOP Modules
Beta Draft Confidential
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/03A-13
Other Standards Supported - E3
• ITU G.751
• ITU G.832
• ITU G.804
• ATM FORUM 94-0406R4
• RFG 1407
Physical Interfaces - DS3
• 8 ATM UNI 3.0/3.1 cell-bearing DS3 ports supporting C-bit/M-framing, PLCP
per TR-TSY-000773, and direct cell mapping per G.804
• BNC connector per ANSI T1.404
Physical Interfaces - E3
• 8 ATM UNI 3.0/3.1 cell-bearing E3 (34.368 Mbps) ports supporting G.751
framing and direct-cell mapping per G.804
• BNC connector per ANSI T1.404
Module Status Indicators
LEDs: Good (green), Failed (red), Redundant (green)
LED State Status
Good ON Normal operation
Failed ON Module failure
Redundant ON Active module (that is, this module is online)
GoodandFailedLEDs
BLINKING simultaneously
OS software image currently being downloaded from the
active SP
