Lucent Technologies CBX 3500 Installation Guide

Installing the CBX 500 Switch
Setting Up the NMS
Beta Draft Confidential
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/034-13
Figure 4-8. Management VC/PVC Method
Using Direct Ethernet
Figure 4-9 shows how to make a direct Ethernet connection from the switch to the
NMS.
Figure 4-9. Direct Ethernet Connection
NMS
IOP Port
Router
ATM NIC
Ethernet
Port
NMS
Ethernet
Port
