363-206-285
Applications
2-22 Issue 3 June 2001
Figure 2-13. OC-1 Ring Transport on OC-3 Ring Configuration
DDM-2000
FiberReach
DDM-2000
FiberReach
DDM-2000
FiberReach
DDM-2000
FiberReach
RT Sites
OC-3
OC-1
Wire Center
Access
System
DDM-2000
OC-3
DDM-2000
OC-3
OC-1 OC-1
SLC
-2000
DS1/EC-1/IS3
Up to 6
separate OC-1
extensions per
DDM-2000 OC-3
Host
Systems
DS1/T1
DS1/T1
DS1/T1
DS1/T1
Multiple
nodes on a
High-Rise
"Fiber in
the Riser"
ring
