Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285
Administration and Provisioning
8-72 Issue 3 June 2001
Orderwire* (E1-Only)
Orderwire* (Multiplexed)
thru, e1dropmain,
e1dropfnc
thru, muxdrop
e1dropmain (Linear)
thru (Ring)
muxdrop (Linear)
thru (Ring)
set-ow
set-ow
set-ow
set-ow
OC-12 degrade threshold §§§
Sync Messaging §§§
AIS alarm level of NSA OC-12
Line AIS §§§
10
-5
to 10
-9
K byte, S byte, disabled
CR, MJ, MN, NA
10
-6
Kbyte
NA
set-oc12
set-oc12
set-oc12
STS-1 path signal
degrade threshold †††
NSA STS-1 path AIS
alarm level
SA STS-1 path AIS
alarm level
STS-1 channel state ***
10
-5
to 10
-9
MN, NR
CR, MN, NA, NR
NMON, AUTO ‡
0 (disabled)
MN
MN
AUTO
set-sts1
set-sts1
set-sts1
set-state-sts1
OC-1 line state NMON, IS IS set-state-oc1
VT1.5 path signal
degrade threshold ***†††
NSA VT path AIS
SA VT path AIS
VT channel state ***
10
-5
to 10
-8
MN, NR
MJ, MN, NA, NR
NMON, AUTO ‡
0 (disabled)
MN
MJ for ring
MN for linear
AUTO
set-vt1
set-vt1
set-vt1
set-state-vt1
DS3 VMR mode †
Clear channel DS3 AIS insertion †
DS3 sig failure alarm level †
DS3 failure threshold †
DS3 PM mode †
DS3 PM frame †
DS3 PM format †
DS3 port state †
VMR, VM, clear channel
yes, no
CR, MJ, MN, NA
10
-3
,10
-6
BER
off, on
m13, cbit
pbit, fmbit, cpbit
NMON, AUTO ‡
VMR
no
CR
10
-3
on
m13
pbit
AUTO
set-t3
set-t3
set-t3
set-t3
set-t3
set-t3
set-t3
set-state-t3
DS1 line coding †
DS1 alarm level †
DS1 AIS insertion †
DS1 failure threshold †
DS1 BPV to LOS †
DS1 PM Mode †
DS1 PM Format †
DS1 primary port state †
AMI, B8ZS, noOverride §
MJ, MN, NA
yes, no
10
-3
,10
-6
,10
-7
,10
-8
BER
yes, no
off, on
sf, esf, esfn
NMON, AUTO ‡
noOverride
NA
yes
10
-3
no
off
esf
AUTO
set-t1
set-t1
set-t1
set-t1
set-t1
set-t1
set-t1
set-state-t1
Environmental alarm level
Environmental alarm type
Environmental alarm description
Control point description
CR, MJ, MN, NA
10 characters
26 characters
26 characters
MN set-attr-env
set-attr-env
set-attr-env
set-attr-cont
Table 8-22. Parameters Provisionable via the CIT—Continued
Parameter Range
Default
(Note 1)
Command
(Note 2)
