363-206-285
Administration and Provisioning
8-70 Issue 3 June 2001
Switch Selectable Parameters 8
Table 8-20 lists the parameters provisionable via hardware switches. Refer to the
command pages in Section 11, "Commands and Reports," for a complete
explanation of parameters.
Table 8-21. Parameters Provisionable via Hardware Switches
CIT Selectable Parameters 8
Table 8-21 lists the parameters provisionable via the CIT. Refer to the command
pages in Section 11, "Commands and Reports," for a complete explanation of
parameters. Additional information on the ID parameters are provided in the
"Identifiers" section immediately following Table 8-21.
Parameter Range Pack
Command
(Note)
Product ID (S1) “Product Type” SYSCTL rtrv-ne
DS1 reference format §
DS1 reference line coding §
Shelf timing mode
SYNC Output LBO ‡
DS1 Output
SF, ESF
AMI, B8ZS
free-running, external DS1, line timed
5 settings (cable dependent)
MULT/SYNC OUT
TG
TG
TG
TG
TG
rtrv-sync
rtrv-sync
rtrv-sync
rtrv-sync
DS1 line coding *
DS1 LBO †
AMI, B8ZS
5 settings (cable dependent)
DS1
DS1
rtrv-t1
DS3 LBO † 2 settings (cable dependent) DS3
STS1E LBO † 2 settings (cable dependent) STS1E
STS1E pack type low-speed STS1E rtrv-eqpt
rtrv-ec1
OW type E1-Only, Multiplexed BBG10 OHCTL set-ow
IMA LAN power settings +5 volt or -48 volt IMA LAN
Note: Current switch settings except DS1 LBO, SYNC Output LBO, DS1 LBO, IMA LAN and STS1E LBO
termination can be reported using CIT.
∗ CIT can override switch settings. (Factory default is
noOverride
.) Parameter can be set for each port.
† Parameter can be set for each circuit pack.
‡ Operational only when in SYNC OUT mode.
§ For both DS1 in and out.
