363-206-285
Technical Specifications
10-70 Issue 3 June 2001
Power Dissipation 10
Table 10-29 lists the power dissipation and current drains for the listed
configurations.
Table 10-29. Power Dissipation and Current Drains
Configuration
Power
Dissipation
(Watts)
DC Current Drains (Amps)
List 1
(-48 V DC)
List 2
(-40 V DC)
OC-3 terminating shelf with
24 DS1 circuit packs (84 DS1s)
66 1.4 1.7
OC-3 terminating shelf with
24 DS1PM circuit packs (84 DS1s)
79 1.6 2.0
OC-3 terminating shelf with
6 DS3 circuit packs (3 DS3s)
58 1.2 1.5
OC-3 STS-1 add/drop shelf with
16 DS1 circuit packs (56 DS1s)
80 1.7 2.0
OC-3 DS1 add/drop shelf with
16 DS1PM circuit packs (56 DS1s)
87 1.8 2.2
OC-3 DS1 add/drop shelf with
8 22F OLIU circuit packs
114 2.4 2.9
EC-1 electrical multiplexer shelf with
24 DS1 circuit packs (84 DS1s)
66 1.4 1.7
EC-1 electrical multiplexer shelf with
24 DS1PM circuit packs (84 DS1s)
73 1.5 1.8
OC-3 terminating shelf with
6 STS1E circuit packs (3 EC-1s)
60 1.3 1.5
OC-3 DS1 self-healing ring shelf with
24 DS1 circuit packs (84 DS1s)
73 1.5 1.8
OC-3 DS1 self-healing ring shelf with
24 DS1PM circuit packs (84 DS1s)
80 1.7 2.0
OC-3 DS1 self-healing ring shelf with 24G-U/
24H-U OLIU and 24 DS1 circuit packs (84
DS1s)
73 1.5 1.8
OC-3 DS1 self-healing ring shelf with 24G-U/
24H-U OLIU and 24 DS1PM circuit packs (84
DS1s)
88 1.8 2.25
OC-3 self-healing ring shelf with
6 STS1E circuit packs (3 EC-1s)
63 1.3 1.6
