Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285
Technical Specifications
Issue 3 June 2001
10-71
The following items should be noted:
■ The DDM-2000 OC-3 shelf accommodates two −48 V power feeders
("A" and "B" office power feeders).
■ Loss of one power feeder does not cause a loss of service.
■ All supply voltages other than −48V required by DDM-2000 OC-3
Multiplexer are generated by DC-to-DC converters within the DDM-2000
OC-3 shelf.
■ The DDM-2000 OC-3 Multiplexer meets all performance requirements
when the DC input voltage varies between −40.0 V and −60.0 V.
■ The DDM-2000 OC-3 Multiplexer tolerates DC input voltages between
0 V and −60 V without damage.
■ The DDM-2000 OC-3 Multiplexer complies with electrical noise tolerance
requirements in Section 13.2 of TR-TSY-000499.
!
CAUTION:
This information is for a typical application only. Consult 801-525-168,
DDM-2000 Floor Plan Data Sheets, and T82046-30, Power Systems DC
Distribution Circuit for Digital Transmission System, for proper engineering
of battery plant and feeders.
OC-3 self-healing ring shelf with
2 OC-3 optical extensions (22G-U/22G2-U)
and 8 DS1PM circuit packs (28 DS1s)
102 2.1 2.5
OC-3 self-healing ring shelf with
6 27G-U/27G2-U dual OC1 OLIUs
111 2.3 2.8
OC-3 DS1 self-healing ring shelf with 29G-U/
29H-U OLIU and 24 DS1 circuit packs (84
DS1s)
78 1.6 1.9*
OC-3 DS1 self-healing ring shelf with 29G-U/
29H-U OLIU and 24 DS1PM circuit packs (84
DS1s)
93 1.9 2.3
DDM-2000 Fan shelf 53 1.1 1.3
Table 10-29. Power Dissipation and Current Drains—Continued
Configuration
Power
Dissipation
(Watts)
DC Current Drains (Amps)
List 1
(-48 V DC)
List 2
(-40 V DC)
OC-3 terminating shelf with
24 DS1 circuit packs (84 DS1s)
66 1.4 1.7
