363-206-285
Circuit Pack Descriptions
Issue 3 June 2001
7-151
Figure 7-51. Optical System Interfaces (Points S and R)
OLIU
Point S
Transmitter
(Tx)
Transmitter/Connector
Assembly
Station Cable
Fiber
Crossconnect
Fiber
Crossconnect
Outside Plant Cable
Connections
OLIU
(Rx)
Assembly
Station Cable
Receiver
Receiver/Connector
Point R
