Administration and Provisioning
8-34 Issue 3 June 2001
Table 8-8 through Table 8-19 lists the various types of cross-connections supported. After
the tables are descriptions of applications and the types of cross-connections each
application requires.
Table 8-8. Ring STS-1 Cross-Connections (Termination/Drop) (Note)
Table 8-9. Ring STS-1 Cross-Connections (Hub/Drop)
From ∗ To “To” CP Type (Note) CIT Command
m-{1-3}
m-{1-3}
m-{1-3}
<-->
<-->
<-->
a
b
c
MXRVO,STS1E,DS3
MXRVO,STS1E,DS3
MXRVO,STS1E,DS3
ent-crs-sts1:m-1,a
ent-crs-sts1:m-2,b
ent-crs-sts1:m-3,c
m-{1,2}†
m-{1,2}†
m-{1,2}†
<-->
<-->
<-->
a
b
c
MXRVO,STS1E,DS3
MXRVO,STS1E,DS3
MXRVO,STS1E,DS3
ent-crs-sts1:m-1,a
ent-crs-sts1:m-2,b
ent-crs-sts1:m-3,c
Note
:
The STS1E circuit pack hardware switch must be set to "low-speed" to support cross-
connections.
∗ Whenever 24-type or 29-type OLIUs are installed in main the range of STS-1s will be
from 1 to 12. Example: m-{1-12}.
† Ring cross-connection; 27-type OLIU in main.
From ∗ To “To” CP Type CIT Command
m-{1-3}
m-{1-3}
m-{1-3}
<-->
<-->
<-->
a-{1,2}
b-{1,2}
c-{1,3}
OLIU
OLIU
OLIU
ent-crs-sts1:m-1,a-1
ent-crs-sts1:m-2,b-2
ent-crs-sts1:m-3,c-3
m-{1,2}†
m-{1,2}†
<-->
<-->
{a,b}-{1-2}
{c}-{1-3}
22-type OLIU
22-type OLIU
ent-crs-sts1:m-1,a-1
ent-crs-sts1:m-1,a-1
∗ Whenever 24-type or 29-type OLIUs are installed in main the range of STS-1s will be
from 1 to 12. Example: m-{1-12}.
† Ring cross-connection; 27-type OLIU in main.
To Next Page
