Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285
Circuit Pack Descriptions
Issue 3 June 2001
7-101
Optical Interface Circuit Packs 7
Table7-2 lists the DDM-2000 OLIU Feature Summary
Table 7-2. DDM-2000 OLIU Feature Summary
OLIU
Line
Rate
(Mb/s)
Span
Length
(Km)
VT/STS Sig.
Degrade
PS TSI
Fiber
Type
Ext.
Atten. System
See
Note
22D-U 155.52 < 3 Yes STS-1/VT1.5 MM No OC-3
22F 155.52 33 No STS-1/VT1.5 SM/MM No OC-3 1, 3
22F-U 155.52 33 No STS-1/VT1.5 SM/MM No OC-3 3
22F2-U 155.52 33 Yes STS-1/VT1.5 SM/MM No OC-3
22G-U 155.52 51 Yes STS-1/VT1.5 SM/MM 7.0 dB OC-3 3
22G2-U 155.52 51 Yes STS-1/VT1.5 SM/MM No OC-3
22G3-U 155.52 55 Yes STS-1/VT1.5 SM/MM No OC-3
22G4-U 155.52 55 Yes STS-1/VT1.5 SM/MM No OC-3
24G-U 622.08 51 Yes STS-1/STS-3c/
VT1.5
SM 8.0 dB OC-3 7
24H-U
26G2-U 51.84 44 Yes STS-1/VT1.5 SM/MM 13.8 dB FiberReach/
OC-1
27G-U 51.84 44 Yes STS-1/VT1.5 SM/MM 13.8 dB OC-3 2
27G2-U 51.84 44 Yes STS-1/VT1.5 SM/MM 13.8 dB OC-3 2, 4
29G-U 622.08 51 Yes STS-1/VT1.5 SM/MM 10 dB OC-1,3 6
29H-U 622.08 94 Yes STS-1/VT1.5 SM 10 dB OC-1,3 6
