363-206-285
Circuit Pack Descriptions
7-8 Issue 3 June 2001
Notes:
1. The switch is set by moving the slide toward the desired position.
2. The FAULT LED will also light if the companion OHCTL is not inserted.
Figure 7-3. BBG8/BBG8B SYSCTL Option Switches
S1
12
ON
OFF
ON
S1
Edge
Connector
Component Side
S2
12345678
ON
OFF
ON
S2
3
