NTP-029: Circuit Order 363-206-285
Page 6 of 22 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
12. At Node 1, install optical splitter in optical line between Node 1
MAIN 1 OUT and Node 2 MAIN 1 IN as shown in Figure 2.
Figure 2 – DDM-2000 OC-3 Point-to-Point to Ring Upgrade
To Next Page
