363-206-285 Circuit Order: NTP-039
Issue 2, February 2000 Page 23 of 32
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED . . . . .FOR DETAILS, GO TO
31. At the last Node (Node 4) and next-to-last Node (Node 3),
disconnect optical fiber from MAIN 1 OUT at Node 4 and FN-C-1
IN at Node 3. Disconnect fiber from MAIN 1 IN at the Node 4 and
FN-C-1 OUT at Node 3. (See Figure 18.)
Figure 18 – DDM-2000 OC-3 Drop or Add/Drop Network to Ring Upgrade
DLP-53232. At Node 1 (CO), locally download TARP Release 13 or later
software. Then use set-fecom:dcc=m2:com=disabled
command to disable DCC at Node 1.
DLP-532
To Next Page
