NTP-060: System Turnup 363-206-285
Page 9 of 12 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
Figure 1 – Example WaveStar TDM 2.5G OC-48/DDM-2000 OC-3 or OC-12
Configurations
WaveStar
TDM 2.5G
WaveStar
TDM 2.5G
DDM-2000
DDM-2000
DDM-2000
Dual homing
configuration [NTP-061]
DDM-2000
DDM-2000
DDM-2000
Single homing
configuration [NTP-060]
DDM-2000
DDM-2000 linear 1+1
extension [NTP-059]
OC-3/OC-12
OC-3/OC-12
OC-3/OC-12
OC-3/OC-12
OC-3/OC-12
OC-48
WaveStar
TDM 2.5G
WaveStar
TDM 2.5G
WaveStar
TDM 2.5G
