Lucent Technologies DDM-2000 OC-3 - Page 1963

TAP-107 : Trouble Clearing 363-206-285
Page 7 of 28 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DS1PM CP failed MJ or MN Internal equipment failure of the specified DS1PM
circuit pack.
DS1 loopback ABN A loopback (toward the optical fiber) is active on
the specified T1 port. (See the opr-lpbk-t1:
and rls-lpbk-t1: commands.)
DS1 loopback (to fiber) ABN A loopback (toward the optical fiber) is active on
the specified T1 port. (See the opr-lpbk-t1:
and rls-lpbk-t1: commands.)
DS1 loopback (to DSX) ABN A loopback (toward the DSX) is active on the
specified T1 port. (See the opr-lpbk-t1: and
rls-lpbk-t1: commands.)
DS1 trmsn test IP ABN A transmission test using the internal test signal
generator and monitor is in progress on the
specified T1 port. (See the test-trmsn-t1:
command.)
DS3 CP failed CR or MN Internal equipment failure of the specified DS3
circuit pack.
DS3 loopback ABN A loopback (toward the optical fiber) is active on
the specified T3 port. (See the opr-lpbk-t3:
and rls-lpbk-t3: commands.)
DS3 loopback (to fiber) ABN A loopback (toward the optical fiber) is active on
the specified T3 port. (See the opr-lpbk-t3:
and rls-lpbk-t3: commands.)
DS3 loopback (to DSX) ABN A loopback (toward the DSX) is active on the
specified T3 port. (See the opr-lpbk-t3: and
rls-lpbk-t3: commands.)
DS3 trmsn test IP ABN A transmission test using the internal test signal
generator and monitor is in progress on the
specified T3 port. (See the test-trmsn-t3:
command.)
EC1 loopback ABN A loopback (toward the optical fiber) is active on
the specified EC1 port. (See opr-lpbk-ec1:
and rls-lpbk-ec1: commands.)
EC1 loopback (to fiber) ABN A loopback (toward the optical fiber) is active on
the specified EC1 port. (See opr-lpbk-ec1:
and rls-lpbk-ec1: commands.)
EC1 loopback (to DSX) ABN A loopback (toward the STSX-1) is active on the
specified EC1 port. (See opr-lpbk-ec1: and
rls-lpbk-ec1: commands.)
TableB–RTRV-ALMMessageDescriptions(Continued)
Description
Alarm
Level Meaning
