363-206-285 Trouble Clearing: TAP-113
Issue 2, February 2000 Page 3 of 6
DDM-2000 OC-3 MULTIPLEXER
14.
NOTE:
There is an automatic lock. An automatic lock occurs when an
automatic
protection switch is made and then broken four times within a 10-minute
interval.
From the Alarm and Status Report, determine the source address of the DS1
circuit pack locked onto the protection DS1.
15. !
CAUTION:
When a
DS1
is switched to protection, removal of any other
DS1
circuit
pack or
177A
Retainer Card in the same group will result in a loss of
service to the protected
DS1
and the removed
DS1
circuit pack.
Replace DS1 service circuit pack locked onto protection.
Reference: DLP-523
16. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
Table A – Obscure Minor Alarm Conditions
Description Meaning Step
APS - automatic lock Service associated with a DS1 circuit
pack has been automatically switched
and locked onto the protection DS1
circuit pack. The APS lock will remain
active until midnight.
Step 14
APS channel failed The APS channel on the protection
OC-3 line has failed.
Step 17
ExternalMinor DC power or fan failure at a remote
terminal far end.
TAP-114
environmentxx A miscellaneous discrete input is active.
This message may be changed using
the set-attr-env: command. The
description may be an alphanumeric
string up to 26 characters long (for
example, Fire, Open door, etc.).
Step 19
protected CP removed A circuit pack previously installed in the
system is removed. The pack should be
replaced or an update (upd) should be
done to remove it from the equipment
list.
Step 21
unexpected CP type
unexpected CP switches
A circuit pack is installed in a slot
provisioned for a different circuit pack,
or switch settings have been changed
from what they were before the circuit
pack was removed.
Step 23
DLP-523
To Next Page
