Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-505
Issue 2, February 2000 Page 6 of 8
DDM-2000 OC-3 MULTIPLEXER
NOTE:
The lightguide jumpers used to loop the OLIUs must be equipped with
ST
®
, FC/PC, or SC connectors at both ends, depending on the type of
OLIU connector (Figures 1, 2, and 3).
NOTE:
The 26G2-U OLIUs can use either single-mode or multimode lightguide
jumpers (Tables D and E). The 22G-U , 24G-U/24H-U , 27G-U/27G2-U ,
and
29G-U/29H-U OLIUs require single-mode lightguide jumpers
(Table D). The 22D-U OLIUs require multimode lightguide jumpers
(Table E).
For the 22D-U
, 22G-U , 24G-U/24H-U , 26G2-U , 27G-U/27G2-U ,or
29G-U/29H-U OLIUs replace the 0 dB LBO on the OUT buildout block(s) with
the required 10 dB LBO on the MAIN 1 or FUNCTION
UNITS-( )-1 OLIUs(TableC).
Table C – Universal 10 dB Lightguide Buildouts
Code Comcode
Connector
Type
Cable
Connection
Label
Color
A3060D1 107406159 SC SM-SM Black
A3070D1 107406191
ST SM-SM Black
A3080D1 107406233 FC/PC SM-SM Black
A2060D 106795289 SC MM-MM Black
A2070D 106795321 ST MM-MM Black
Table D – Single-Mode Lightguide Jumpers
Code Comcode Length (Feet) Connectors
FS1E-E-2 105357727 2 ST-ST
LS1SC-SC-2 106908247 2 SC-SC
LS1FP-FP-10 106593825 10 FCPC-FCPC
Table E – Multimode Lightguide Jumpers
Code Comcode Length (Feet) Connectors
FL1E-E-2 105351795 2 ST-ST
LL1SC-SC-2 106908668 2 SC-SC
LL1FC-FC-10 106095549 10 FC-FC
