Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-507
Issue 2, February 2000 Page 1 of 4
DDM-2000 OC-3 MULTIPLEXER
Install DS3/TMUX Circuit Packs
1.
!
CAUTION:
Take care to avoid damaging the LEDs that protrude through the opening
in the faceplate of the DS3/TMUX .
NOTE:
DS3/TMUX circuit packs may be installed in FUNCTION UNITS group
slots A, B,orC. BBG4/BBG4B DS3 and BBG20 TMUX service circuit
packs are installed in slots labeled FUNCTION UNITS ( ) 1.
BBG4/BBG4B DS3 and BBG20 TMUX protection circuit packs are
installed in slots labeled FUNCTION UNITS ( ) 2(P). BBG19 DS3 data
interface circuit packs are installed in both FUNCTION UNITS ( ) 1 & 2(P)
slots and are independent. There is no protection between the BBG19
DS3 circuit packs.
Determine which FUNCTION UNITS group slot(s) (A(), B()or C()) is being
equipped with DS3/TMUX circuit packs.
2. Determine from office records the length of the DS3 cabling between the
DDM-2000 and the DSX-3 cross-connect point.
3.
NOTE:
The only hardware option settings on DS3 circuit packs are the LBO
settings shown in Figures 1 and 2. If there are other jumpers on the
circuit pack similar to the LBO jumpers, they are factory test points and
should be ignored.
Refer to Table A and Figures 1 and 2. Install the DS3 option jumpers per
Tabl e A.
Table A – DS3 LBO Settings
Cable Length (Ft)
734A
735A
1735006A LBO Setting
0 to 225 0 to 125 LBO IN
>225 to 450 >125 to 250 LBO OUT
