DLP-509: Detailed Level Procedure 363-206-285
Page 1 of 2 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
Perform LED Test
1.
!
CAUTION:
Take care to avoid damaging the LEDs that protrude through the
openings in the faceplates of the circuit packs.
Is a CIT available?
If YES, then continue with Step 2.
If NO, then proceed to Step 5.
2. Connect CIT to User Panel.
Reference: DLP-521
3. Use the test-led:address:r=( ) command to test LEDs.
Where address = address identifier of the system, slot, or user panel
that contains the LEDs to be tested. Default is all.
r = number of times (1 through 10) test is repeated.
Response: All LEDs for the specified address identifier light. For a
SYSCTL LED test, all segments of the SYSCTL FE ID
display (including the period) light. After 10 seconds, all
LEDs go off. After another 10 seconds, a completion
message is printed and all LEDs are updated to show the
current status of the system.
4. Did LED test pass?
If YES, then STOP. YOU HAVE COMPLETED THIS PROCEDURE.
If NO, then proceed to Step 7.
