Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-514 Issue 2, February 2000 Page 7 of 18
DDM-2000 OC-3 MULTIPLEXER
Table C – DDM-2000 OC-3 to OC-3 Measured Optical Power and Required LBO
Transmitter
Receiver
22F OLIU
22G-U OLIU
22F-U/22F2-U OLIU
22G2-U/22G3-U OLIU
22G4-U OLIU
22D-U OLIU
(Controlled Env.)
22D-U OLIU
(Uncontrolled Env.)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
22F/22F-U/22F2-U OLIU –8.0 to –10.0 10 –8.0 to –10.0 10
–10.0 to –15.0 5 –10.0 to 15.0 5
–8.0 to –34.0 0 0.0 to –34.0 0 –15.0 to –33.8 0 –15.0 to –31.8 0
22G-U/22G2-U/22G3-U/
22G4-U OLIU
0.0 to –5.0 15 0.0 to –5.0 15
0.0 to –3.0 10 –5.0 to –10.0 10 –5.0 to –10.0 10
–3.0 to –8.0 5 –10.0 to –15.0 5 –10.0 to –15.0 5
–8.0 to –34.0 0 0.0 to –34.0 0 –15.0 to –33.8 0 –15.0 to –31.8 0
22D-U OLIU
(Controlled &
Uncontrolled Env.)
(MM Fiber Only)
–14.0 to –15.0 5 –14.0 to –15.0 5
–14.0 to –34.0 0 –14.0 to –34.0 0 –15.0 to –34.0 0 –15.0 to –31.8 0
Notes:
1. Measured power is defined to be the measured power of the light emitted from receive fiber connector at OLIU.
2. The minimum measured received power allows for optical path penalty and unallocated margin. Connector loss is not allotted for; it should already
be accounted for in the optical power measurement.
3. The margin for falling within the max rx power is 1.0 dB.
