363-206-285 Detailed Level Procedure: DLP-514
Issue 2, February 2000 Page 11 of 18
DDM-2000 OC-3 MULTIPLEXER
Table E – DDM-2000 OC-3 to FT-2000 LS INTFC Measured Optical Power and Required LBO
Transmitter
Receiver
LAA10 OC3
(FT-2000)
LAA5 IS3
(FT-2000
22F OLIU
22G-U OLIU
22F-U/22F2-U OLIU
22G2-U/22G3-U OLIU
22G4-U OLIU
22D-U OLIU
(Controlled Env.)
22D-U OLIU
(Uncontrolled Env.)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
LAA10 OC3
(FT-2000)
0.0to–5.0 15 0.0to–5.0 15
–5.0 to –10.0 10 –5.0 to –10.0 10 0.0 to –3.0 10
–10.0 to –15.0 5 –10.0 to –15.0 5 –3.0 to –8.0 5
–15.0 to –34.0 0 –7.0 to –34.0 0 –15.0 to –33.8 0 –8.0 to –34.0 0
LAA5 IS3
(FT-2000)
–5.0 to –14.0 10
–14.0 to –15.0 5 –14.0 to –15.0 5 –14.0 to –15.0 5 –14.0 to –15.0 5
–15.0 to –34.0 0 –15.0 to –34.0 0 –15.0 to –33.8 0 –15.0 to –34.0 0
22G-U/22G2-U/22G3-U/
22G4-U OLIU
0.0to–5.0 15
0.0 to –3.0 10 –5.0 to –10.0 10
–3.0 to –8.0 5 –10.0 to –15.0 5
–8.0 to –34.0 0 –15.0 to –30.8 0
22D-U OLIU –14.0 to –15.0 5
–14.0 to –34.0 0 –15.0 to –30.8 0
22F/22F-U/22F2-U OLIU –8.0 to –10.0 10
–10.0 to –15.0 5
–8.0 to –34.0 0 –15.0 to –30.8 0
Notes:
1. Measured power is defined to be the measured power of the light emitted from receive fiber connector at OLIU.
2. The minimum measured received power allows for optical path penalty and unallocated margin. Connector loss is not allotted for; it should already be accounted for in the optical
power measurement.
3. The margin for falling within the max rx power is 1.0 dB.
