Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-514
Issue 2, February 2000 Page 18 of 18
DDM-2000 OC-3 MULTIPLEXER
Figure 8 – Sample Report From rtrv-map-neighbor Command (R15)
18. After all connections and tests have been made, verify optical fiber cables are
placed correctly in fiber tray/rings and properly routed in bay framework.
Reinstall front cover and tighten three screws.
19. Repeat this procedure for each fiber span to be connected until the end-to-end
system is established.
20. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
/* Neighbor Map for Site6NE1
=================================================================
TID Connected Thru Product Type Level 2 IS DCC
NSAP
=================================================================
Site6NE1 DDM-2000 OC-3 Y
39 840F 80 000000 0000 0000 0000 08006alad06e 00
Site7NE1 main-1 N
39 840F 80 000000 0000 0000 0000 08006alad06f 00
Site5NE1 main-2
39 840F 80 000000 0000 0000 0000 00000e3a0372 00
*/
