363-206-285 Detailed Level Procedure: DLP-515
Issue 2, February 2000 Page 2 of 4
DDM-2000 OC-3 MULTIPLEXER
NOTE:
If local procedures prohibit you from doing the init-pm:reg=all
command, you may perform the following in Steps 5 and 6. Use the
rtrv-pm-line: command to obtain the line performance monitoring
status report, note the readings on the current time line in the report,
wait 20 seconds and then obtain another report. There should be no
change in readings from the first report.
Enter the command init-pm:reg=all,ifallowed.
4. Wait 20 seconds.
5. Enter one of the following commands:
• rtrv-pm-line:main-1 if service line is being tested.
• rtrv-pm-line:main-2 if protection line is being tested.
• rtrv-pm-line:main-all if both lines are being tested.
Response: The following CIT report will indicate the status of the
equipment. The current time line should indicate that
there are no errors. Other time lines may exist with
numbers greater than zero. (The Commands and Reports
section of this manual under RTRV-PM-LINE describes
this report.)
/* Line Performance Monitoring Status Report
Last initialized: day registers at yy-mm-dd hh:mm:ss
quarter hour registers at yy-mm-dd hh:mm:ss
========================================================================
Address Start B2 CV B2 ES B2 ESA B2 UAS PSC-L PJC
Time B2 SES B2 ESB
========================================================================
address time nn nn nn nn nn nn
. .. .....
. .. .....
. .. .....
------------------------------------------------------------------------
address time nn nn nn nn nn nn
. .. .....
. .. .....
. .. .....
*/
