363-206-285 Detailed Level Procedure: DLP-531
Issue 2, February 2000 Page 1 of 2
DDM-2000 OC-3 MULTIPLEXER
Retrieve Generic Software Version ID
1. Is a CIT available?
If YES, then continue with Step 2.
If NO, then proceed to Step 5.
2. Connect CIT to User Panel and establish session.
Reference: DLP-521
3. Use the rtrv-eqpt:sysctl command to retrieve generic software version
number.
Response: System outputs an Equipage and Version Report
which contains the program version presently loaded into
the system.
4. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
5.
NOTE:
When the ACO button is depressed, all LEDs and the 7-segment display
on the SYSCTL light. If the ACO button is released within 2 seconds, the
LED test completes and the 7-segment display and all LEDs will revert to
normal operation. If the ACO button is depressed longer than 2 seconds,
the 7-segment display goes blank for 2 seconds and then each digit of
the generic software version code is scrolled through the display. The
LEDs remain lighted while the code is being displayed. When the ACO
button is released, the LEDs remain lighted until the full software version
code is displayed. If the ACO button is still depressed when the software
version code has completed cycling, the display goes blank for 2 seconds
and starts cycling through the software version code again. This
continues as long as the ACO button is depressed. When the ACO
button is released the cycle will complete and the display and all LEDs go
to normal operation.
Depress and hold (for longer than 2 seconds) the ACO buttonontheUser
Panel.
Response: All LEDs and the 7-segment display light. The display
goes blank for 2 seconds and then scrolls through the full
software version code.
6. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
DLP-521
To Next Page
