Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-546
Issue 2, February 2000 Page 4 of 20
DDM-2000 OC-3 MULTIPLEXER
Figure 4 – Sample Report From rtrv-map-neighbor Command (R15)
2. Verify system configuration is same as specified on work order or circuit order.
3. From work order or circuit order, determine the terminating (drop) nodes for
the service being established.
4.
NOTE:
In single ring configurations, cross-connections consist of pass-through
cross-connections in addition to the terminating cross-connections. For
example in Figure 1, if the terminating nodes are at Node 1 and Node 5,
then pass-through cross-connections will have to be made at Nodes 2, 3,
4 and 6.
/* Neighbor Map for Site6NE1
=================================================================
TID Connected Thru Product Type Level 2 IS DCC
NSAP
=================================================================
Site6NE1 DDM-2000 OC-3 Y
39 840F 80 000000 0000 0000 0000 08006alad06e 00
Site7NE1 main-1 N
39 840F 80 000000 0000 0000 0000 08006alad06f 00
Site5NE1 main-2
39 840F 80 000000 0000 0000 0000 00000e3a0372 00
*/

Lucent Technologies DDM-2000 OC-3 Specifications

General

Brand	Lucent Technologies
Model	DDM-2000 OC-3
Category	Multiplexer
Language	English
