DLP-559: Detailed Level Procedure 363-206-285
Page 1 of 12 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
Make Cross-Connections Using CIT
Single/Dual Homing and OC-3 or OC-12 Extensions
OC-48/OC-3 or OC-48/OC-12 Configuration
1.
NOTE:
If you are not familiar with doing cross-connections using the CIT
commands, it is strongly suggested that you read Cross-Connection
Provisioning in the Administration and Provisioning section of this manual
and the appropriate documentation in the FT-2000 User/Service Manual.
Also, read the description of the following commands in the Commands
and Reports section of this manual and the DDM-2000 OC-3 manual:
ent-crs-sts1, ent-crs-vt1, rtrv-crs-sts1, rtrv-crs-vt1,
dlt-crs-sts1, and dlt-crs-vt1.
NOTE:
You will have to login to more than one node in each ring to get a
complete map of the network using the rtrv-map-network: and
rtrv-map-neighbor: command. If a drawing of the network is not
provided with the work order, it is recommended that you draw a simple
schematic of the network before making cross-connections.
Make a simple drawing of the network and list the TID of each node and how
they are connected to each other. Figures 1 through 7 show examples of
simple schematics.
2. Log into any node in each ring in the network and use the
rtrv-map-network: and/or rtrv-map-neighbor: command to retrieve a
map of the network which lists all the systems and how they are connected to
each other.
