Lucent Technologies DDM-2000 OC-3 User Manual

DLP-560: Detailed Level Procedure 363-206-285
Page 6 of 18 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
Log in to any node in each ring in the network and use the
rtrv-map-network: and/or rtrv-map-neighbor: command to retrieve a
map of the network which lists all the systems and how they are connected to
each other.
Sample output reports are shown in Figures 5, 6, and 7:
Figure 5 – Sample Report From rtrv-map-network Command
/* Network Map for Site6NE1
==============================================================
TID Product Type Level 2 IS
NSAP
==============================================================
Site6NE1 DDM-2000 OC-3
39 840F 80 000000 0000 0000 0000 08006alad06e 00
R5
39 840F 80 000000 0000 0000 0000 00000e3a0273 00
R6
39 840F 80 000000 0000 0000 0000 08006alad07f 00
R7
39 840F 80 000000 0000 0000 0000 00000e3a0732 00
Site3NE1 Y
39 840F 80 000000 0000 0000 0000 00000e3a0372 00
Site7NE1
39 840F 80 000000 0000 0000 0000 08006alad06f 00
*/
