363-206-285 Detailed Level Procedure: DLP-560
Issue 2, February 2000 Page 11 of 18
DDM-2000 OC-3 MULTIPLEXER
12. Use the rtrv-crs-vt1: or rtrv-crs-sts1: command to verify that the
proper connections have been made. If an improper cross-connection is made,
use the dlt-crs-vt1: or dlt-crs-sts1: command to delete the improper
cross-connection and reenter the cross-connection.
13. At OC-12 terminating nodes equipped with BBG11B 3DS3 circuit packs, use
the set-trace-sts1: command to verify the proper cross-connect path of a
STS-1 cross-connected STS-1 signal.
14. After all cross-connections are made, use the rtrv-alm: command to verify
no alarms are present.
15. If DS3 cross-connections have been established and the terminating nodes
are equipped with BBG4B DS3 circuit packs, use set-trace-sts1:
command to check integrity of cross-connect path.
Reference: DLP-563
16. If ne-acty, inc. VT AIS, inc. STS1 AIS, inc. VT unequipped,or
inc. STS1 unequipped alarms are present, look for missing or improperly
made cross-connections. Use TAP-120 to locate missing cross-connections, if
required.
DLP-563
TAP-120
