Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285
Circuit Pack Descriptions
7-22 Issue 3 June 2001
Figure 7-8 shows the location of the option switches for the BBF2B/BBFY TGS circuit pack.
Figure 7-8. TG Option Switches for DDM-2000 OC-3 (Sheet 1 of 2)
Notes:
1. The switches are set by moving the slide toward the desired position.
2. If the invalid switch setting is selected, the FAULT LED lights and an alarm is
generated.
1234
ON
OFF
S1
5
123
ON
OFF
S2
Edge
Connector
Component Side
