Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285
Circuit Pack Descriptions
Issue 3 June 2001
7-99
Maintenance Signal Functions 7
The BBG20 TMUX detects the following DS3 signal failures from the DSX-3:
■ LOS
■ OOF
■ AIS
■ BER.
The BBG20 TMUX inserts DS1 AIS on all DS1 outputs (toward fiber) upon
detection of DS3 LOS, OOF, and AIS, and DS2 OOF.
Transmission - Optical Interface 7
Universal Optical Connector 7
Circuit packs having a "-U" after their designation indicate that these circuit packs
have a universal optical connector.
The following circuit packs are available with the connector:
■ 22D-U OLIU
■ 22G-U/22G2-U/22G3-U/22G4-U* OLIU
■ 24G-U/24H-U OLIU
■ 22F-U/22F2-U
■ 26G2-U OLIU
■ 27G-U/27G2-U OLIU
■ 29G-U/29H-U*
*Ship with SC buildout and ST shiped loose with each pack.
This connector, 29G-U/29H-U (Figure 7-38), is a two-part connector consisting of
a faceplate-mounted block and an optical buildout. The faceplate block optionally
supports an
ST
®
, SC, or FC-type optical buildout.
A0dB
SC -type connector is shipped as standard with each OLIU. Optional ST 0
dB buildouts are shipped loose with each OLIU. Optional SC, ST, or FC-PC 0 dB
or attenuated buildouts can be ordered separately. See Chapter 10, "Technical
Specifications," for a list of universal buildout attenuators. All OLIU’s will phase to
SC buildout mountd and ST shipped loose.
