To reduce the possibility of ESD damage, shelves are equipped with grounding
jacks to enable personnel to ground themselves using wrist straps (see Figure A)
while handling circuit packs or working on a shelf(s). The jacks for connection of
wrist straps are located at the lower right-hand corner of each shelf and are
labeled. When grounding jacks are not provided, an alligator clip adapter enables
connection to bay frame ground.
Figure A. Static Control Wrist Strap
To
Ground
Connection
