363-206-285
Administration and Provisioning
Issue 3 June 2001
8-31
29-type
Add/Drop
STS
15.0 15.0 15.0 15.0 15.0
Add/Drop
VT
15.0 15.0 15.0 13.0,
11.1
Dual 0x1
STS
15.0 15.0 15.0
Dual 0x1
VT
15.0 15.0 15.0
Dual 0x1 NR
STS
15.0
Single 0x1
STS
15.0 15.0 15.0
Single 0x1
VT
15.0 15.0 15.0
Single 0x1 NR
STS
15.0
Drop/Continue
STS
15.0 15.0
Drop/Continue
VT
15.0 15.0
Locked
VT
15.0 15.0
Dual Locked
STS
Add/Drop
STS-3c
15.0
*
A 22-type OLIU in a function unit and provisioned with STS-1 or VT1.5 cross-connects is in “linear” (unprotected
or 1+1 line protected), not a ring configuration. A 22-type OLIU in function unit C and provisioned with an STS-3c
cross-connect is in a dual 0x1 configuration.
†
This table refers to only “low-speed” STS-1 interfaces.
‡
Only FN-B and/or FN-C can be equipped with 22-type OLIUs in this release.
§
FN-A, FN-B and/or FN-C can be equipped with 22-type OLIUs in this release.
¶
This entry valid for DS3 circuit packs except the BBG19 front-access pack.
**
This entry valid for the BBG19 front-access DS3 circuit pack.
††
One of the pair of function unit slots will be empty.
‡‡
All VT1.5 drop and continue cross-connections in a system must be in the same direction, i.e. from the same ring
(m1 or m2).
§§
The mixing of 0x1, Pass-Through, and local Add/Drop cross-connects is supported beginning with R13.0.
¶¶
The mixing of 0x1, Pass-Through, and local Add/Drop cross-connects is supported beginning with R11.0.
^
Introduced in Release 15.0.
From
MAIN
To
FUNCTION UNIT
Circuit
Pack
Cross-Connect
Type 22-type
*
26G2-U 27G-U 27G2-U DS3 STS1E
†
MXRVO TMUX
