363-206-285
Administration and Provisioning
Issue 3 June 2001
8-41
Provisioning now as a VT1.5 cross-connect will avoid a hit on traffic if
the STS-1 cross-connect has to be converted to 28 VT1.5 cross-
connects (cnvt-crs)todropDS1satalatertime.
c. On STS-1 path-switched rings, all nodes in the ring must be
provisioned as STS-1 cross-connections.
To do a cross-connection successfully, proper addressing of cross-connect points is
necessary. Figure 8-2 shows example STS-1 addresses. For a complete list of
valid addresses, refer to Table 8-5 through Table 8-17.
Figure 8-2. Example of STS-1 Addresses
M
A
I
N
STS-1 #1
STS-1 #2
OLIU
(m-1)
(m-2)
Function Unit A
MXRVO
(a)
Function Unit B
DS3
(b)
OLIU
STS-1 #1
STS-1 #2
(c-1)
(c-2)
Function Unit C
STS-1 #3
STS-3c
(m-3)
(m-1)
STS-1 #3
STS-3c
(c-3)
(c-1)
