363-206-285
Administration and Provisioning
Issue 3 June 2001
8-49
or 29-type OLIUs in Main can be used with any of the following combination,
BBF1B, BBF3, BBF6, BBF8, BBF9/BBF10, and BBF3B:
Note that the table below does not represent all the different combinations of Low
Speed circuit packs that can co-exist in the Low Speed slots at one time.
NOTES
* = Using a BBG2 (MXRVO) circuit pack in the corresponding Function Unit group
** = Using a BBG2B (Enhanced MXRVO) circuit pack in the corresponding
Function Unit group
Any time T1EXT is used, BBG2B MXRVO packs must be used.
DS1/T1EXT/HDSL packs can be protected
The above table is subject to change.
General:
DS1 ===> BBF1, BBF1B, BBF3, and BBF3B
T1EXT ===> BBF6
HDSL ====> BBF8
LAN ====> BBF9/BBF10
Cross-Connection and Other Provisioning Changes Related to the Addition of
LAN Low-Speed Interface on the OC-3 Shelves
DS1/T1EXT
Packs HDSL LAN
5* 1* 1*
5** 3** 0
3** 3** 1**
3** 1** 2**
2** 0** 3**
0** 3** 2**
0** 2** 3**
