363-206-285
Applications
Issue 3 June 2001
2-15
Figure 2-9. Multinode OC-3 Ring With OC-12 Ring Transport
DDM-2000
OC-12
STS-1 Path Switched
OC-12 Ring
DDM-2000
OC-3
DDM-2000
OC-12
DDM-2000
OC-12
DDM-2000
OC-12
DDM-2000
OC-12
DDM-2000
OC-3
DDM-2000
OC-3
DDM-2000
OC-3
DDM-2000
OC-3
Single
Homed
OC-3 Ring
Dual
Homed
OC-3 Ring
