Maeda CC1908S-1 - Reversing; Stopping

M A E D A Crawler Crane 5.3 MACHINE TRAVELLING
5/2020 CC1908S-1 5-17
5.3.3.2 REVERSING
1. Place the lock lever (1) in the "Free"
position.
2. Operate the right and left travel levers as
follows:
• If the sprocket (A) is at the rear of the
machine, pull the travel levers slowly
toward you to start moving.
• If the sprocket (A) is at the front of the
machine, push the travel levers (5) slowly
forward to start moving.
5.3.3.3 STOPPING
Avoid sudden stops and try to stop with a safety
margin where possible.
• Place the right and left travel levers in the
neutral position (N).
The machine stops.
