Maeda CC1908S-1 - Unloading

5.11 TRANSPORT M A E D A Crawler Crane
5-90 5/2020 CC1908S-1
Place timber strips between the wire
ropes and the machine to prevent
damage to the wire rope and machine.
5.11.2.3 UNLOADING
1. Select a level and firm road surface for
unloading the machine. Also, keep a safe
distance away from the roadside.
2. Apply the trailer brake securely. Place wheel
chocks next to the wheels to prevent the
trailer from moving.
3. Secure the ramps in place so that the
centreline of machine aligns with the
centreline of the trailer.
Position the left and right ramps so they
are parallel and the same distance from
either side of the trailer centreline.
The angle of the ramps must not
exceed 15 degrees.
Securely hang the hooks of the ramps
on to the hooks on the trailer.
If the ramps bend under the machine
weight, place lumber or other blocks
under the ramps to prevent bending.
4. Remove the chains or wire ropes securing
the machine.
5. Start the engine.
In cold conditions, warm up the engine fully.
6. Place the lock lever in the free position (F).
7. Set the travel speed to 1st speed.
To change the travel speed, press the travel
1st speed/2nd speed selector switch.
8. Fix the direction toward the ramps and
slowly travel down to unload. Do not operate
any lever other than the travel levers here
while travelling on the ramps.
