M A E D A Crawler Crane 6.11 BATTERY COMPARTMENT DOOR
5/2020 CC1908S-1 6-21
BATTERY
COMPARTMENT DOOR
CAUTION
When performing inspection and maintenance
inside the door, use a stopper to ensure the
door stays open.
1. Insert your fingers into the door handle (1)
and open the door (2).
2. After opening the door (2), insert the rod (3) in
the slot to secure it in place.
3. To close the door (2), lift the rod (3) to remove
it from the slot and close the door.
LEFT COVER
CAUTION
• When performing inspection and
maintenance inside the door, use a stopper
to ensure the door stays open.
• Be sure to lock the door except when
opening it.
1. Unlock the door lock (1).
2. Insert your fingers into the door handle (2)
and open the door (3).
3. After opening the door (3), insert the rod (4) in
the slot to secure it in place.
4. To close the door (3), lift the rod (4) to remove
it from the slot and close the door.
5. Lock the door.
