5.11 TRANSPORT M A E D A Crawler Crane
5-92 5/2020 CC1908S-1
3.
Stop the engine and remove the starter
switch key. Check that there is nothing
around the operator's seat, and get off the
machine.
4.
Close all the doors, windows, and covers.
Lock all the lockable doors, covers, and
caps.
5.
Attach the hoisting wires and shackles to the
machine body. Be sure to hoist from four
points, as shown in the following figure:
6.
Lift the machine slowly.
Immediately after lifting off the ground,
stop briefly to check the state of the
hoisting accessories and slinging
posture.
To Next Page
