M A E D A Crawler Crane 6.4 PARTS REPLACEMEMT
5/2020 CC1908S-1 6-9
OTHER REPLACEMENT PARTS
Part numbers may change as a consequence of product improvement, so please check with us or our sales
service agency for the latest part number by referring to the machine number.
No. Part name Quantity
1 Front windscreen (lower) 1
2 Front windscreen (upper) 1
3 Roof window 1
4 Side window (right) 1
5 Rear window 1
6 Side window (left) 1
7 Door window (upper) 1
8 Door window (lower) 1
9 LED lights 2
10 Interior lamp (10 W bulb) 1
No. Part name Quantity
11 Winch mirror 1
12 Fuse box 1
-
13 Fuse box 2 -
14 Fusible link 1
-
15 Fusible link 2 -
16 Fan belt
2
17 A/C compressor belt 1
For details on individual fuse ratings, refer to
"6.7 FUSES" on P. 6-16 and "6.8 FUSIBLE
LINKS" on P. 6-17.
