M A E D A Crawler Crane 3.1 MAIN SPECIFICATIONS
5/2020 CC1908S-1 3-3
Equipment / Item Fly jib
Weight and
dimensions
Main body weight + 500 kg
Overall length × width × height 7,480 mm × 2,490 mm × 3,015 mm
Equipment / Item Blade
Weight and
dimensions
Main body weight + 950 kg
Overall length × width × height 7,380 mm × 2,490 mm × 3,015 mm
Equipment / Item Searcher hook
Weight and
dimensions
Main body weight + 70 kg
Overall length × width × height 8,230 mm × 2,490 mm × 3,015 mm
Performance
Maximum rated total load ×
working radius
2.0 t × 7.14 m (Searcher Hook)
1.52 t × 8.0 m (Winch)
Maximum working radius 20.73 m
Maximum lifting height above ground 22.6 m
