Malfunctions in driving mode
7.5 Fuses
Operating Manual GMK6300L 3 112 xxx en 7 - 21
xx.xx.xxxx
Group F2
Group F3
s
Designation Amperage (A) Function
F2/1 10 Tachograph, radio, control unit ESX 3
F2/2 15 Warm water auxiliary heating
1)
F2/3 3 Ignition lock
F2/4 15 Heater fan
F2/5 10
Automatic parking light
1)
Power supply
1)
F2/6 10 Retarder
1)
, air-conditioning system
1)
F2/7 15 ABS trailer
F2/8 3 Low-beam headlight
1)
Designation Amperage (A) Function
F3/1 15 Rotating beacon
F3/2 10
Flame start system
1)
,
Vehicle height monitoring
1)
F3/3 15
Warm water auxiliary heater
1)
,
Ignition lock
F3/4 20
Air drier, mirror adjustment,
Window winder
F3/5 15
Outrigger lighting, spotlights on the rear
of the carrier
1)
F3/6 10 Turn signal indicators
F3/7 10 Windscreen wiper/washing system, horn
F3/8 10 Reversing lamps, trailer socket
1)
Additional equipment
