Malfunctions in driving mode
7.5 Fuses
7 - 22 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
Group F4
Group F5
Designation Amperage (A) Function
F4/1 15
Instrument lighting, trailer socket, engine
brake
F4/2 10
Battery heating
1)
,
Particulate filter
1)
F4/3 10 Central lubrication
F4/4 10 Power supply
F4/5 10 Tachograph
F4/6 10
Engine electronic system, ECOS control
unit
F4/7 10 diagnostics plug
F4/8 10 TCM supply
Designation Amperage (A) Function
F5/1 5 Generator
F5/2 5
Emergency stop system, air intake
inhibitor
1)
F5/3 5 Power supply CAN BUS
F5/4 20 Power supply ESX3 control unit
F5/5 5 Air intake inhibitor
1)
F5/6 10 Engine electronic system (ADM, SCR)
F5/7 2 Emergency operation, ESX 3 control unit
F5/8 5 Fog tail light
1)
Additional equipment
